RDK X3Simplify Robotic Development with RDK X3

Buy now

Individual developers

Empowering every developer with their own intelligent development kit, coupled with D-robotics's high-performance algorithm toolchain and a wealth of development cases, to assist developers in crafting premium applications.

Industrial sectors

Wide range of module types and delivery options are available for selection, complemented by the abundant peripheral resources provided by our ecosystem partners, further empowering customers to bring their products to market.

Robust Processinng Capabilities

· 5T computing power· Multicore isomerism· Operator acceleration· Memory optimization

RDK X3

RDK X3 Module

RDK X3 Module Developer Kit

· CPUQuad-core ARM® Cortex® A53@1.5G

· RAM2GB/4GB LPDDR4 RAM

· BPUDual-core Bernoulli Arch, 5Tops

· Storage16GB/32GB/64GB eMMC or Micro SD

· MultimediaH.265 (HEVC) Encoding and DecodingMain profile, L5.14K@60fps, JPEG Encoding and Decoding 16Mpixels

· SensorMIPI CSI 2lane x 2

· USB HostUSB Type-A 3.0 x 1 USB Type-A 2.0 x 2

· USB DeviceMirco USB 2.0 x 1

· Debug Uart1 x Debug UART

· Display1 x HDMI1.4 (up to 1080p60)

· Wireless networkWi-Fi 2.4/5GHz Bluetooth 4.2

· Wired networkRJ45 interface

· 40PINGPIO&I2C&UART&SPI&I2S&PWM

· Power input5V 3A

· System supportUbuntu 20.04/22.04

100+ Robot development kits to help accelerate product assembly

We provide a variety of development kits, ranging from various sensors to multiple controller modules, and diverse forms of robots (drones, unmanned vehicles, wheeled robots, robotic arms, etc.), to help expedite the implementation of your robot solutions.

100+ open-source algorithms and applications to accelerate comprehensive development

A selection of applications from various categories within NodeHub, ranging from sensor configuration to robot application development, are available. Everything you need is here, so feel free to explore and use them.
